The strand is tacked with all the bent area of the guy grip.Ī guy clamp is used on the communication line. The guy grip is also known as the guy grip end or preformed guy grip, it’s used to link and traction grounding cable, the conductor, and the optical fiber program. The guy grip has formed legs using grits on each turn that retains the messenger conductor wire or fiber optic cable securely.
The guy wire preforms join the anchor rod or insulator to achieve the use of setting the pole. Guy wire is designed to use with several fittings and components for different applications, and they are used together to provide stability to towers, antennas, and other utility structures.Īccording to the program, the dead end grip comprises guy wire dead end grips, preformed dead end grip used on the conductor, and preformed grip.
#GUY WIRE INSULATOR INSTALL#
Guy wires for telecommunications and broadcastingīe clear that NEVER install a mast near AC power lines. Guy wires used to support the telephone pole or antenna mast are about the same as they are for the power system. Note: A guy wire is usually used with a guy set, which is insulated to avoid electric shock if any person touches it. Because of the enormous tension stress of utility lines between the poles or towers, on the opposite side, guy wires are connected from the pole to the ground to support the unbalanced lateral loads, make sure the structures be straight and prevent the ground from moving. Utility Lines run for longer distances with many utility poles or towers, and they need to cross many places. Guy wire attache d on the ground What is the application of a guy wire? An anchor concreted into the solid ground can is used to hold one or more guy wires steady. One side of a guy wire is connected to a point high up on the structure, and the other hand is anchored to a safe point on the solid ground, creating a diagonal line. Guy wire attached to the top of the power pole
It is used to support kinds of electric poles and towers in the power system, or hold up aerial masts for broadcasting and communications. Guy (red arrow), controlling the spinnaker pole How is a guy wire used?Ī guy wire is designed to transfer some of the weight of the structures to the ground. When it came to any line used to keep something stable, it was also named strand wire, stay wire, guy strand, guy cable, guy anchors, sometimes mistakenly called ”guide wire” (The word guide is of French origin which has nothing to do with guy wire). The guy derives from a Dutch word, gei, which was a rope used to fix a furled sail to a mast. The cables bear a high tension, so for industrial purposes, the cable consists of wires of galvanized steel, which makes the guy wires extremely strong.
#GUY WIRE INSULATOR HOW TO#
The more-massive DXE-504 insulators take that number to 12,000 lbs. These porcelain insulators accept large guy lines, dead ends or bent-pin shackles and are suitable for all guyed towers where breaking strength for each insulator is not exceeded.ĭXE-502 insulators are rated at 10,000 lbs. DX Engineering Porcelain Guy Line Strain Insulators provide the strength, insulation and isolation you need for guyed tower systems.
